MANKIND Sureshot 20 Bike semi matte trans bronze
- Artikel-Nr.: 22MKSU20SMBTB
Beschreibung
The Sureshot was the hotseller in our last year`s bike line and the name says it all! The Sureshot is a great value priced model equipped with many Mankind aftermarket parts and also the Shadow Strada Nuova Tires 2.3”. This bike is designed to be an allround, allterrain machine with a quick and responsive geometry and handling.
Key features:
100% Chromoly TT & DT
Mankind Advance Alloy Stem NEW
Mankind Control Grips
Mankind Control Sealed Front Hub
Mankind Control Sealed Cassette Hub
Shadow Strada Nuova Tires 2.3”
Geometry:
Top Tube Length: 20,5“, XL: 21.0“
Chain Stay Length: 13.25"
Head Tube Angle: 75.0°
Stand Over Height: 9.0″
Bar Height: 8.9"
Fork Offset: 28mm
Weight: 11.3 kg / 24.91 lbs for Sureshot
Colors: Semi Matte Trans Bronze, Gloss Trans Blue,
XL: Semi Matte Trans Burnt Orange, Gloss Trans Raw
FRAME 1020 Hi-Ten Steel Frame – TT & DT 100% Chromoly - MK TT & DT Gusset
TOP TUBE 20.5” – XL: 21.0”
CHAIN STAY 13.25”
HEAD TUBE 75°
SEAT TUBE 71°
BB HEIGHT 11.75”
STAND OVER 9.0”
BRAKE MOUNTS Welded
FORK 1020 Hi-Ten Steel - 2-PC Chromoly Steerer, Tapered Legs, 28mm offset
BARS 1020 Hi-Ten Steel - 8.9” Rise, Back: 12°/ Up: 2°, Width: 29.0”
GRIPS Mankind Control Grips
BAR ENDS Mankind Nylon
STEM Mankind Advance Stem - Alloy - 50mm reach
HEADSET Mankind Control Sealed Integrated
BRAKE Alloy U-brake
BRAKE LEVER Alloy Lever - 2-Finger Design - Hinged
REAR HUB Mankind Control Cassette Hub – Sealed - 14mm axle - 9t Driver
FRONT HUB Mankind Control Sealed – Male 3/8” Axle
SPROCKET Mankind Control Alloy 25t
CRANKS Chromoly – 8 Spline - 3-Piece - 170mm - 19mm
BOTTOM BRACKET Mid BB Sealed - 19mm
CHAIN PYC 410 - black
PEDALS Mankind Control Plastic
FRONT RIM Alloy - Double Wall 36H
REAR RIM Alloy - Double Wall 36H
SPOKES Steel Spokes – 14mm nipples - black
FRONT TIRE Shadow Strada Nuova LP 2.30”
REAR TIRE Shadow Strada Nuova LP 2.30”
PEGS None
SEAT Mankind Control Mid Seat/Post Combo debossed
SEAT POST Seat/Post Combo
SEAT POST CLAMP Mankind Control Alloy - black
COLORS Semi Matte Trans Bronze, Gloss Trans Blue, XL: Semi Matte Trans Burnt Orange, Gloss Raw
WEIGHT 11,30 kg
